“The periodical cicada four-year acceleration hypothesis revisited and the polyphyletic nature of Brood V, including an updated crowd-source enhanced map (Hemiptera: Cicadidae: Magicicada)”
Authors: John R. Cooley​, Nidia Arguedas, Elias Bonaros, Gerry Bunker, Stephen M. Chiswell, Annette DeGiovine, Marten Edwards, Diane Hassanieh, Diler Haji, John Knox, Gene Kritsky, Carolyn Mills, Dan Mozgai, Roy Troutman, John Zyla, Hiroki Hasegawa, Teiji Sota, Jin Yoshimura, and Chris Simon.
Abstract:
The periodical cicadas of North America (Magicicada spp.) are well-known for their long life cycles of 13 and 17 years and their mass synchronized emergences. Although periodical cicada life cycles are relatively strict, the biogeographic patterns of periodical cicada broods, or year-classes, indicate that they must undergo some degree of life cycle switching. We present a new map of periodical cicada Brood V, which emerged in 2016, and demonstrate that it consists of at least four distinct parts that span an area in the United States stretching from Ohio to Long Island. We discuss mtDNA haplotype variation in this brood in relation to other periodical cicada broods, noting that different parts of this brood appear to have different origins. We use this information to refine a hypothesis for the formation of periodical cicada broods by 1- and 4-year life cycle jumps.
There is a new paper out about Brood XXII, titled Evolution and Geographic Extent of a Surprising Northern Disjunct Population of 13-Year Cicada Brood XXII (Hemiptera: Cicadidae, Magicicada). I helped with the field work for this paper, traveling through Ohio and Kentucky with Roy Troutman, recording the locations of periodical cicadas.
Brood XXII, a brood of Magicicada periodical cicadas with a 13-year lifecycle, exists in Louisiana & Mississippi, and Ohio & Kentucky with no geographic connection between them (the two groups are geographically isolated). The paper discusses the similarities and differences between the two groups.
Citation for the paper:
Gene Kritsky, Roy Troutman, Dan Mozgai, Chris Simon, Stephen M Chiswell, Satoshi Kakishima, Teiji Sota, Jin Yoshimura, John R Cooley; Evolution and Geographic Extent of a Surprising Northern Disjunct Population of 13-Year Cicada Brood XXII (Hemiptera: Cicadidae, Magicicada), American Entomologist, Volume 63, Issue 4, 12 December 2017, Pages E15—E20, https://doi.org/10.1093/ae/tmx066
Is it true that someone has offered a reward for a white or blue-eyed Magicicada cicadas?
This was false and an urban legend until in 2008 when Roy Troutman began to offer rewards for living blue-eyed cicadas for scientific research. All cicadas were released, unharmed.
Important: Roy is no longer offering the reward as he has obtained the cicadas needed for his research. So, don’t bug him, unless you want to tell him that his photos and video are awesome.
White or Blue-eyed Magicicadas cicadas are extremely rare, so finding them can be difficult. I usually find one per emergence, and that is after looking at thousands of cicadas.
Speaking of Roy and White-eyed cicadas, here is a video Roy took of a White-eyed cicada:
And here’s a white and orange-eyed cicada photo taken by Roy:
Here is a video of a rare white eyed magicicada. This is from a gene mutation that strepps the color from the cicadas eyes & also wings to some extent.
Cicadas breathe through apertures along the side of their body called spiracles. This video of a Tibicen by Roy Troutman shows the opening and closing of a spiracle.
Update: After emailing with Dave Marshall and John Cooley today (July, 17th), I learned that the ‘decim cicadas in this brood are Magicicada tredecim (not neotredecim), based on their lower-pitched sound and very-orange abdomens! This means that this brood is not related to Brood XIV or X at all, that these cicadas are truly 13-year cicadas, they might be related to Brood XXII and perhaps were once part of the same larger brood thousands of years ago.
Read on:
Back in 2013 Roy Troutman and his wife Michelle visited me in New Jersey to experience the Brood II cicada emergence. At that time, Roy extended an invitation to visit Ohio in 2014 to experience & map a mysterious brood that emerges every thirteen years near his family campsite. A year later, I took him up on his offer.
A very orange M. tredecim found by Roy in Ohio.
On June 1st I made the long drive from the Jersey Shore to south-west Ohio. The trip went smoothly, thanks to a well maintained car, a flash drive filled with 37 Gig of music, Red Bull, Monster Energy Drinks, some M&M candies and a tank and a half of gas. Sunday night I met Roy at his family home. After a quick dinner, we immediately went looking for cicadas in Point Pleasant, Ohio. Most of the cicadas had emerged from the ground a week or two ago, but we were able to find a few newly emerged specimens:
The following morning we visited the Crooked Run-Robert J. Paul Memorial Sanctuary in Chilo, Ohio, which is primarily a hardwood forrest along the Ohio River. The nature sanctuary was loaded with Magicicada tredecassini, healthy pockets of M. tredecula and a few M. tredecim. The cicadas were chorusing, feisty and already ovipositing (laying eggs).
So, why spend a week researching cicadas? Why ride in a car for dozens of hours tracking the locations of cicadas? Well, this mysterious Ohio & Kentucky brood is unique, and this would be the first time it was thoroughly mapped.
Why is this Ohio Kentucky brood unique?
These cicadas have a 13-year life cycle. No other brood of periodical cicadas in Ohio has a 13-year life cycle. Note that two 13-year broods (XIX & XXIII) exist in Kentucky, but they are geographically isolated from the OH/KY brood.
The OH/KY brood is also geographically isolated from Brood XXII, a brood of 13-year cicadas that emerged in Louisiana and Mississippi this year (2014). The OH/KY brood might be grouped with Brood XXII just by virtue of the fact that they emerge in the same cycle of years, but the two broods seem to be too far apart, geographically and probably genetically, to be related.
They occupy a relatively small area of south-western Ohio, and north-central Kentucky.
They are in relatively the same area as two 17-year broods, Brood XIV and Brood X. Brood XIV more so than Brood X.
The mystery is: why does this small, isolated brood of 13-year cicadas exist?
Roy Troutman and John Cooley have collected specimens, and the insects genetics will be studied to try to find an answer. Along with the results of genetic testing, the results of mapping will be considered, along with the past work of researchers like Lloyd and White, and local legend Gene Kritsky.
Mapping cicadas:
Mapping cicadas requires that you drive hundreds to thousands of miles, listening for cicadas, and recording the species and location. The hard parts are 1) picking out the individual species (particularly hearing individual deculas in the midst of loud chorus of cassini), and 2) driving slow enough to hear the individual species, without enraging local drivers. Discerning the songs of individual species is easy enough when you’re moving slowly or standing still, but at 55mph, you can hear the roar of a cassini chorus, but a more subtle ‘decim chorus, set deeper in the woods, will go unheard.
Thanks to John Cooley’s Map O Matic — a combination of a tiny laptop, Ubuntu Linux, a numeric keypad, a GPS puck, and some clever programming — marking the locations of Magicicada species is now a simple task. Drive around, and when you hear a heavy ‘decim chorus, you hit the 9 key, and the location is recorded. Hear a ‘cassini individual; hit a 4, and the location is recorded. Genius. I suppose the next best thing would be an app version.
The Cicada Map O Matic
Each day Roy planned the route and we started mapping. Roy driving; me pressing buttons. We traveled highways, and single-laned roads; through heavily populated suburbia with convenience stores selling Pork cracklings and fireworks, as well as, farm and forrest roads. Straight and fast. Winding and bumpy. Each day was amazing road trip for the sake of cicada research.
Mapping can be frustrating. Time limitations are frustrating. The cicadas only sing for a few weeks, so there is only so much time to hear and map them.
Google Maps, often used to visualize cicada mapping data, is frustrating as well. Google maps omits unincorporated towns and villages from their maps. Want to find Utopia, Ohio on Google Maps? According to Google Maps, it doesn’t exist.
Also, if you use an old map, beware; a road that existed 10 years ago, might now be a rocky field. One time we headed down a dusty road that looked like it connected to a major county road. Instead, Roy ended up breaking some part of his car on some bowling ball sized rocks, which I had to get out and move so we could backtrack to civilization. One positive: while rolling boulders, I heard an individual Magicicada tredecim, which are rare in this brood. Hit the 7 on the cicada Map O Matic.
The data from all this cicada mapping will be used by cicada researchers like Gene Kritsky and John Cooley to decode the mystery of this brood. If you’re curious, you can see the map here, or take a look at this short video, which crudely demonstrates the geographic proximity of Brood XIV, the OH/KY Brood and Brood X:
My trip to Ohio and Kentucky, was fantastic. I got to spend dozens of hours helping to map an important brood, hang out with a good friend, and even meet cicada research legend Gene Kritsky for breakfast. For a cicada fanatic, it doesn’t get much better.
A Magicicada tredecassini found in Kincaid Park, Kentucky.
I had such a good time, I headed home via Kentucky (which is not the way to go, if you’re going back to New Jersey). I stopped by Kincaid Park so I could hear all three species in one location. I even drove down the shoe road, and visited the Jim Beam distillery (which has little to do with cicadas, but why not).
After spending a week mapping cicadas, my respect for cicada researchers like Gene, John, Roy, Chris Simon, David Marshall and Jin Yoshimura has grown measurably. Mapping is not easy. It takes concentration, patience, a lot of expensive gasoline, and energy drinks. It’s worth it though. Hopefully I’ll get to do it again next year as well.
