December 2, 2015

The Smaller Neotibicen

Filed under: Identify,Neotibicen,Tibicen — Dan @ 10:32 pm

This is my third, and possibly final, article on identifying Neotibicen, using the information on this website. Read the other articles, Identifying Neotibicen and Large Neotibicen.

Identifying the smaller Neotibicen is no easy task — with two exceptions.

The two easy ones are:

1) Neotibicen superbus, aka the Superb Cicada, because it looks like no other cicada in this group. It is pea green with bright yellow arches on its mesonotum. No other Neotibicen shares that coloration. No other cicada in the group sounds quite like it either.

Superb Cicada
Photo by Sloan Childers.

2) Neotibicen latifasciatus, aka Coastal Scissors Grinder Cicada, because it has a white X (pruinose) on its back. Otherwise, it looks like four other cicadas, kinda like four more, and sounds like three others.

While I’ve never heard an actual scissor being sharpened with a grinder, it must sound like the repetitive, rhythmic, short grinding sounds like cicada makes. Grind, Grind, Grind, Grind.

Neotibicen latifasciatus
Photo by me of Bill Reynolds’ collection.

The rest of the small Neotibicen closely resemble each other enough to make many scratch their heads in wonder. BugGuide.net organizes these cicadas into four groups4: the “Green Tibicen Species” (Tibicen is the old genus name for these cicadas), “Southern Dog-day Cicadas”, “Swamp Cicadas”/”The chloromerus Group”, and the “Lyric Cicadas”/”The lyricen Group”. I’ll use these groups for this article for consistency sake. These groups are also closely related genetically1, although Neotibicen similaris, which BugGuide puts under “Southern Dog-day Cicadas”, is a bit of an outlier1. Tables below might be a bit overwhelming — but they help to accurately align the similarities between these cicadas.

As you browse this page, if you click the cicada’s name you’ll be brought to a page that features more information about that cicada, including sound files, location information, links to other websites, and often more photos and video. When in doubt: visit the BugGuide Dog Day Cicada page.

The Green Neotibicen

These Neotibicen all share green markings on their pronotum, mesonotum, and pronotal collars. Find a Neotibicen with a green collar, and there’s a good chance it is one of these. As you can see, these insects are well camouflaged for an adult life in trees.

Green Neotibicen
Photo credits l to r: Roy Trountman, Tom Lehmkuhl , Paul Krombholz, me.

Cicada Sounds Like Looks Like Looks Kind of Like
N. canicularis (Harris, 1841) aka Dog-day Cicada

The canicularis varies the most in terms of coloration. Some are very dark, with more black than green, and others have an even amount of green and black.
Sounds like an angle grinder tool grinding something.
N. auriferus
N. davisi davisi
N. davisi harnedi
N. auriferus
N. davisi davisi
N. davisi harnedi
N. latifasciatus
N. linnei
N. pruinosus pruinosus
N. robinsonianus
N. winnemanna
N. latifasciatus (Davis, 1915) aka Coastal Scissor(s) Grinder Cicada

If the cicada has a white X on its back, it is a latifasciatus.
Repetitive, rhythmic, call – like someone repeatedly running a scissor over a grinding wheel (I suppose).
N. pruinosus fulvus
N. pruinosus pruinosus
N. winnemanna
N. linnei
N. pruinosus pruinosus
N. robinsonianus
N. winnemanna
N. auriferus
N. canicularis
N. davisi davisi
N. davisi harnedi
N. linnei (Smith and Grossbeck, 1907) aka Linne’s Cicada

Known for the bend of their wing.

Linne’s cicada’s call builds up — a crescendo — peaks, and then fades back down.
N. tibicen australis
N. tibicen tibicen

It sounds like the N. tibicen species, but unlike them, it calls from high in the trees.
N. latifasciatus
N. pruinosus pruinosus
N. robinsonianus
N. winnemanna
N. auriferus
N. canicularis
N. davisi davisi
N. davisi harnedi
N. pruinosus fulvus Beamer, 1924 aka Yellow morph of Scissor Grinder.

This cicada should look like the other cicadas in this table, but its coloring is more yellow than green, like a teneral Scissor Grinder.
N. latifasciatus
N. pruinosus pruinosus
N. winnemanna
N. pruinosus pruinosus (Say, 1825) aka Scissor(s) Grinder

The Scissor Grinder looks a lot like Linne’s Cicada but their wing doesn’t have bend that Linne’s Cicada has. The Scissor Grinder also seems to have more of an orange coloration to the “arches” on its mesonotum.
Its call is like N. latifasciatus, but it is faster paced.
N. latifasciatus
N. pruinosus fulvus
N. winnemanna
N. latifasciatus
N. linnei
N. robinsonianus
N. winnemanna

N. auriferus
N. canicularis
N. davisi davisi
N. davisi harnedi
N. robinsonianus Davis, 1922 aka Robinson’s Annual Cicada or Robinson’s Cicada

Robinson’s Cicada looks like Linne’s Cicada with less of a wing bend, and a different call.
Its call is kind of like N. latifasciatus, but much more raspy.
N. latifasciatus
N. linnei
N. pruinosus pruinosus
N. winnemanna

N. auriferus
N. canicularis
N. davisi davisi
N. davisi harnedi
N. winnemanna (Davis, 1912) aka Eastern Scissor(s) Grinder

Like the Scissor Grinder, the Eastern Scissor Grinder seems to have more of an orange hue to the arches on its mesonotum, perhaps even more so than the Scissor Grinder.
Its call is similar to the Scissor Grinder.
N. latifasciatus
N. pruinosus fulvus
N. pruinosus pruinosus
N. latifasciatus
N. linnei
N. pruinosus pruinosus
N. robinsonianus
N. auriferus
N. canicularis
N. davisi davisi
N. davisi harnedi


Neotibicen canicularis (Green Group) and Neotibicen davisi (Southern Dog Day Group) compared. Photo by Paul Krombholz

Southern Dog Day

Cicada Sounds Like Looks Like Looks Kind of Like
N. auriferus (Germar, 1834) aka Plains Dog-day Cicada

Coloration varies from rusty browns to greens.
Sounds like an angle grinder tool grinding something.
N. canicularis
N. davisi davisi
N. davisi harnedi
N. davisi davisi
N. davisi harnedi
N. canicularis
N. latifasciatus
N. linnei
N. pruinosus pruinosus
N. robinsonianus
N. winnemanna
N. davisi davisi (Smith and Grossbeck, 1907) aka Davis’ Southeastern Dog-Day Cicada

The davisi comes in a wide variety of colors: from rusty browns to greens.
Sounds like an angle grinder tool grinding something.
N. auriferus
N. canicularis
N. davisi harnedi
N. auriferus
N. davisi harnedi
N. canicularis
N. latifasciatus
N. linnei
N. pruinosus pruinosus
N. robinsonianus
N. winnemanna
N. davisi harnedi Davis, 1918

Looks like Davis’ Southeastern Dog-Day Cicada but with slight differences in the wings.
Sounds like an angle grinder tool grinding something.
N. auriferus
N. canicularis
N. davisi davisi
N. auriferus
N. davisi davisi

N. canicularis
N. latifasciatus
N. linnei
N. pruinosus pruinosus
N. robinsonianus
N. winnemanna
N. superbus (Fitch, 1855) aka Superb Dog-Day Cicada

This cicada is the most unique looking: solid green with prominent yellow arches on its back.
Its call is so unique, you’ll have to listen to it and decide what it sounds like.
N. similaris (Smith and Grossbeck, 1907) aka Similar Dog-Day Cicada

This cicada is similar to the Neotibicen tibicen species in shape (hump back) and coloring.
N. tibicen tibicen

Swamp Cicadas

Swamp Cicadas are often the easiest cicadas to find, because they prefer to stay in the lower branches of trees. Listen for one, and you’ll likely be able to spot it in the tree above you.

Cicada Sounds Like Looks Like Looks Kind of Like
N. tibicen tibicen (Linnaeus, 1758) aka Swamp Cicada

Swamp Cicadas are are known for their rounded, humped back. Their coloration varies from mostly black & some green to black, brown and green. Their collar is usually black, but can include green.
Its call builds up — a crescendo — peaks, and then fizzles out.
N. linnei
N. tibicen australis
N. tibicen australis N. similaris
N. tibicen australis (Davis, 1912) aka Southern Swamp Cicada

Southern Swamp Cicadas look like Swamp Cicadas, but they are more colorful. Their collars are often green & black.
Its call builds up — a crescendo — peaks, and then fizzles out.
N. linnei
N. tibicen tibicen
N. tibicen tibicen N. similaris

Lyric Cicada and Swamp Cicada compared
Top: Swamp Cicada; Bottom: Lyric Cicada. Note the more rounded shape of the Swamp Cicada’s mesonotum. Photo by me.

Lyric Cicadas

The Lyric Cicadas all look physically similar, but their coloration is unique enough to tell them apart. They usually have brown/black collars, which makes it easy to tell them apart from the “Green” Neotibicen. They also resemble the Swamp Cicadas, but Lyric cicadas have flatter mesonotums, and Swamp Cicadas are less likely to have black collars.

Dark Lyric Cicada
Dark Lyric Cicada. Photo by Roy Troutman.

 Lyric Cicada
Lyric Cicada. Photo by me.

Cicada Sounds Like Looks Like Looks Kind of Like
N. lyricen engelhardt (Davis, 1910) aka Dark Lyric Cicada

The Dark Lyric Cicadas have the darkest coloration of all the Lyric cicadas. Their mesonotum is almost entirely dark brown/black. They have a “soda-pop pull-tab” or keyhole shape on their pronotum.
Its sound is like an angle grinder tool steadily grinding a slightly uneven surface.
N. lyricen lyricen
N. lyricen virescens
N. tibicen tibicen
N. lyricen lyricen
N. lyricen virescens
N. lyricen lyricen (De Geer, 1773) aka Lyric Cicada

The Lyric cicada, like most small Neotibicen, has a green, black & brown camouflage look, but the key is Lyric cicadas typically have black collars.
Its sound is like an angle grinder tool steadily grinding a slightly uneven surface.
N. lyricen engelhardti
N. lyricen virescens
N. tibicen tibicen
N. lyricen engelhardti
N. lyricen virescens
N. lyricen virescens Davis, 1935 aka Costal Lyric Cicada

The Costal Lyric cicadas can be distinguished from other Lyric cicadas by their vibrant turquoise-green colors.
Its sound is like an angle grinder tool steadily grinding a slightly uneven surface.
N. lyricen engelhardti
N. lyricen lyricen
N. tibicen tibicen
N. lyricen engelhardti
N. lyricen virescens

1Molecular phylogenetics, diversification, and systematics of Tibicen Latreille 1825 and allied cicadas of the tribe Cryptotympanini, with three new genera and emphasis on species from the USA and Canada (Hemiptera: Auchenorrhyncha: Cicadidae) by Kathy B. R. Hill, David C. Marshall, Maxwell S. Moulds & Chris Simon. 2015, Zootaxa 3985 (2): 219–251. Link to PDF.

3 Cicadas of the United States and Canada East of the 100th Meridian.

4BudGuide.net’s Dog Day Cicadas Page.

###

I will update & augment this article over time.

For more information about these cicadas, visit the North American Cicadas page and our U.S.A. & Cicada Search Page

November 29, 2015

The Large Neotibicen

Filed under: Identify,Neotibicen,Tibicen — Dan @ 6:45 pm

One way to simplify the identification of Neotibicen is to categorize them into large and small Neotibicen. The physically larger Neotibicen are closely genetically related 1, as well as being physically larger. BugGude.net breaks this group into three categories: “the auletes group” (N. auletes, N. resh, N. resonans, N. figuratus), “the pronotalis group” (N. dealbatus, N. pronotalis, N. cultriformis) and “the dorsatus group” (N. dorsatus, N. tremulus)2.

Tibicens of the Eastern USA
Large Neotibicen cicadas are arranged along the top row in this photo by cicada researcher Kathy Hill. Note the “T.” in their names stands for the older genus name “Tibicen”.

Let’s compare them based on their visual and audio characteristics.

4 Cicadas Compared
Photo credits l to r: Paul Krombholz, me (from Bill Reynolds’ collection), Paul Krombholz, Joe Green.

Click the names of the cicadas to listen to their songs, find their geographic range, and to see more images and video.

Cicada Sounds Like Looks Like Notes
Neotibicen auletes (Germar, 1834)
aka Northern Dusk Singing Cicada
N. resh, N. resonans, N. figuratus Largest Neotibicen; olive to tan, brown, black & white pruinosity. No distinct markings. Sings at dusk.
Neotibicen resh (Haldeman, 1852)
aka Resh Cicada
N. auletes, N. resonans, N. figuratus Smaller green Neotibicen Distinctive resh (ר) markings on mesontum. Its call is like a sped-up, shorter version of N. auletes’ call.
Neotibicen resonans (Walker, 1850)
aka Southern Resonant/Great Pine Barrens Cicada
N. auletes, N. resh, N. figuratus N. figuratus Brown, black & white pruinosity distinctively present within curves of the cruciform elevation Its call is like a bland version of the N. resh call.
Neotibicen figuratus (Walker, 1858)
aka Fall Southeastern Dusk-singing Cicada
N. auletes, N. resh, N. resonans N. resonans Brown, black & with pruinosity. Its call has more character than N. figuratus, but is not as sonically impressive as N. auletes.

3 more cicadas
Photo credits l to r: Roy Troutman, me (from Bill Reynolds’ collection), Bill Lesar.

Cicada Sounds Like Looks Like Notes
Neotibicen dealbatus (Davis, 1915) N. pronotalis walkeri, N. pronotalis pronotalis Orange form looks like N. dorsatus & tremulus, but “stripes” on abdomen of dealbatus are unique. Primarily either orange/rust or pea green, brown, black with heavy pruninosity which forms distinct markings on dorsal side of body. Dorsal side has two black stripes framed by three areas of pruinosity.
Neotibicen pronotalis pronotalis Davis, 1938 N. dealbatus, N. pronotalis walkeri N. pronotalis pronotalis Tan or pea green, brown, black, and sometimes white pruinose. Wing color matches dominant color of body. Often features a black marking on pronotum3.
Neotibicen pronotalis walkeri Metcalf, 1955
aka Walker’s Cicada
N. dealbatus, N. pronotalis pronotalis N. pronotalis walkeri Tan or pea green, brown, black, and sometimes white pruinose. Wing color matches dominant color of body. Typically lacks a black marking on its pronotum.
Neotibicen cultriformis (Davis, 1915)
aka Grand Western Flood Plain Cicada
Orange/rust, black & pruinosity on head & body. Wings are green! Found only in Arizona and New Mexico.
Neotibicen dorsatus (Say, 1825)
aka Bush Cicada or Grand Western or Giant Grassland Cicada
N. tremulus N. tremulus, the Orange form of N. dealbatus (although tremulus lacks pruinose “stripes”) Rust/orange, black & white pruinosity, which forms distinct markings, such as a line of white dots down the dorsal side of the abdomen.
Neotibicen tremulus Cole, 2008
aka Bush Cicada
N. dorsatus N. dorsatus, the Orange form of N. dealbatus (although tremulus lacks pruinose “stripes”). Rust/orange, black & white pruinosity, which forms distinct markings, such as a line of white dots down the dorsal side of the abdomen. The pitch of the tremulus’ call is different than dorsatus, which is one way to tell them apart.

I will update this page over time to clarify & improve the information. I hope it helps.

1 Molecular phylogenetics, diversification, and systematics of Tibicen Latreille 1825 and allied cicadas of the tribe Cryptotympanini, with three new genera and emphasis on species from the USA and Canada (Hemiptera: Auchenorrhyncha: Cicadidae) by Kathy B. R. Hill, David C. Marshall, Maxwell S. Moulds & Chris Simon. 2015, Zootaxa 3985 (2): 219–251. Link to PDF.

2 Species Neotibicen auletes http://bugguide.net/node/view/6968.

3 Cicadas of the United States and Canada
East of the 100th Meridian http://insectsingers.com/100th_meridian_cicadas/index.html.

November 23, 2015

Identifying Neotibicen

Filed under: Identify,Neotibicen,Tibicen — Dan @ 8:12 pm

Identifying cicadas can be quite challenging, especially cicadas belonging to the Neotibicen genus. Different Neotibicen species often look and sound alike, and it takes a lot of practice before one gets good at identifying them. I only know 5 or 6 people in the world that I would trust to tell a Neotibicen winnemanna from a Neotibicen pruinosus, for example, because their songs and visual appearance are so similar.

In this article, I will first point out various sources where to you learn about the different Neotibicen species. Then I will discuss basic terminogy used when describing cicadas. Last, I will discuss some challenges with identifying them. Subsequent articles will discuss the specific species and subspecies.

Resources

The best sources for identifying Neotibicen, IMHO, are:

  • Insect Singers for audio recordings of cicada songs.
  • The work of Bill Reynolds and others on BugGuide.net, for example, the Info page for N. pruinosus. BugGuide is particularly useful for getting a cicada identified — you upload a photo, and they identify it. You can also try to figure it out yourself by browsing their catalog of images.
  • The recent paper Molecular phylogenetics, diversification, and systematics of Tibicen Latreille 1825 and allied cicadas of the tribe Cryptotympanini, with three new genera and emphasis on species from the USA and Canada (Hemiptera: Auchenorrhyncha: Cicadidae) by Kathy B. R. Hill, David C. Marshall, Maxwell S. Moulds & Chris Simon. 2015, Zootaxa 3985 (2): 219–251. (link to the paper). This paper is useful for understanding the morphology of Neotibicen as well as how the various species are genetically related.
  • Biogeography of the Cicadas (Hemiptera: Cicadidae) of North America, North of Mexico by Allen F. Sanborn and Polly K. Phillips. (Download PDF). This document is particularly useful for locations.
  • The Cicadas (Hemiptera: Cicadoidea: Cicadidae) of N. America North of Mexico by Allen F. Sanborn and Maxine S. Heath. (the book is available here)

You can also use this website as a resource. The Cicada Species of North America and USA & Canada Cicada Search are useful.

Terminology

  • Eyes: Neotibicen have 5 eyes, but for the purposes of identification, the two big, composite eyes are most important.
  • Mask: a mask, in terms of cicadas, is a dark band between their eyes. Not all cicadas have this, but when they do, it can be useful for identification. Mask
  • Pronotum: the dorsal surface of the first segment of the thorax. The word means “before back” in Greek.
  • Pronotal Collar or simply Collar: a collar-like band that separates the head and thorax.
  • Mesonotum: a shield-shaped structure that covers the dorsal side of the second segment of the thorax. The name means “middle shield” in Greek. This is where the arches or “M” appears on the cicada.
  • Cruciform Elevation: a cross-shaped structure found on the dorsal side at the end of the thorax
  • Pruinose: a white, waxy substance found on the bodies of many cicadas. Pruinosity refers to the degree to which the cicada’s body features pruinose.
  • Costal Margin & Wing Shape in general: The costal margin is the outer edge of the cicada’s forewing. The shape of the wing can help you diagnose the species. Wing Bend
  • Abdomen: The third, last and final portion of the cicada’s body (1st: head, 2nd: thorax, 3rd: abdomen).
  • Dorsal: The top side of the cicada.
  • Ventral: The bottom side of the cicada — where the legs are.
  • Teneral: Teneral means soft, and in the case of cicadas, it refers to the adult cicada when it has recently molted and is still soft/unsclerotized.
  • Song: Neotibicen males sing using their tybmals, which are drum-like organs located in their abdomen.

Cicada Anatomy

Those are the resources and terminology — now on to the challenges.

Rules are not absolute

Sometimes a diagnostic characteristic is fool-proof for the majority of identifications, but in some cases it fails.

Example: N. lyricen typically have black collars, but not 100% of the time. You might find a lyricen with a green collar, and think it is a N. linnei.

Hybridization

Neotibicen like canicularis, linnei, pruinosus, robinsonianus & winnemanna, are closely related, and cicada researchers have found evidence that they hybridize, based on hybrid songs or mixed characteristics.

See Bill Reynolds’ information on hybrids on BugGuide.

Live vs. Dead

Dead specimens lose color over time. Eyes lose color. Vibrant greens become dull. Dull greens become yellow or brown. Keep that in mind.

Eye Colors Fade

Teneral vs Adult

When cicadas molt, and their bodies as still soft, they are often lighter in color and the markings on their skin are not clearly defined.

2 hours of change

Some previous articles about identifying teneral Neotibicen:

Lighting

Photograph the same cicada in direct sunlight, indoors with a flash, or without a flash under florescent lighting, and it might appear different each time.

The eyes, in particular, look different under different lighting conditions.

Name changes

The names of all plants and animals change over time, for several reasons. An old book or paper about Neotibicen might feature names that have completely changed. Neotibicen tibicen tibicen, for example, was called Tibicen chloromera not long ago.

See major changes to the Tibicen genera for information about the recent change from Tibicen to Neotibicen. I haven’t had to the time to update all the Tibicens to Neotibicens on this website — some day I will.

And in case you wanted to know:

How to tell if a Neotibicen is a male or female.

###

The next article will discuss the Larger Neotibicen species.

August 16, 2015

Color variations in Neotibicen tibicen tibicen

Filed under: Neotibicen,Tibicen — Dan @ 8:25 am

Color variations in chloromera
The cicada on the Left was found in Middletown NJ, and the cicada on the Right in Metuchen, NJ. Middletown is closer to the ocean than Metuchen is, but both share a similar elevation and vegetation.

It is interesting to note the color variation found in Neotibicen tibicen tibicen aka chloromera aka Swamp Cicada aka Hunch-Back cicada.

In some areas the dorsal side of N. tibicen tibicen can be almost all black, while in other locations their pronotums & mesonotums feature vibrant greens & rusty browns — you can even make out the “M” on the mesonotum.

There may have been cross breeding between the Southern Swamp Cicada (Neotibicen tibicen australis), at some point in time, providing some Neotibicen tibicen tibicen with more colorful appearance. Read Intergrade zones with australis on BudGuide for more information on that possibility.

August 8, 2015

Neotibicen lyricen engelhardti aka Dark Lyric Cicada

Filed under: Neocicada,Tibicen — Dan @ 8:38 am

This female Neotibicen lyricen engelhardti aka Dark Lyric Cicada was found during my lunch (half) hour in Middletown, NJ (95ft elevation). Yes it is covered with ants.

Neotibicen lyricen engelhardti cicada female

More information about N. lyricen engelhardti.

August 3, 2015

Tibicen bermudiana, an extinct cicada

Filed under: Extinct,Neotibicen,Tibicen — Tags: — Dan @ 5:33 am

The Tibicen bermudiana Verrill (T. bermudianus if you want the genus and species names to agree, and maybe now Neotibicen bermudianus) is a cicada that was endemic to Bermuda and is now extinct. Its closest relative is the Tibicen lyricen, which is found in the United States (and not extinct).

Here is a photo of a T. bermudiana from the collection found at the Staten Island Museum:

Tibicen bermudiana of Bermuda

More photos.

From the Bermuda’s Fauna website:

Sadly, when most of the Bermuda cedar trees were killed of by a blight in the 1950s, the cicadas that made the nights so uniquely magical and romantic in sound also largely disappeared.

Updated with a photo of the coin commemorating this cicada:

Coin

July 10, 2015

Major Changes to the Tibicen genera

Sometimes you wake up and the whole world is different. See this cicada:

A female teneral Tibicen tibicen tibicen (chloromera) cicada
photo by me.

… when I went to sleep she was a Tibicen tibicen tibicen, but now I know she is a Neotibicen tibicen tibicen. 10 years ago, she was a Tibicen chloromera. 130 years ago, she was Cicada tibicen. Cicada names change as researchers discover their differences.

Two new papers have split the Tibicen (or Lyristes) genera into many genera: Tibicen (European Tibicen), Auritibicen (Tibicen of Asia/Japan), Neotibicen (mostly eastern North American Tibicen), and Hadoa (Tibicen of the western United States).

The first paper is Description of a new genus, Auritibicen gen. nov., of Cryptotympanini (Hemiptera: Cicadidae) with redescriptions of Auritibicen pekinensis (Haupt, 1924) comb. nov. and Auritibicen slocumi (Chen, 1943) comb. nov. from China and a key to the species of Auritibicen by Young June Lee, 2015, Zootaxa 3980 (2): 241–254. This paper establishes the new genera Auritibicen, and the members of the Tibicen/Lyristes genera fall into that genera. Here is a link. So, Tibicen flammatus aka Lyristes flammatus of Japan, for example, becomes Auritibicen flammatus.

Tibicen flammatus aka Lyristes flammatus
Auritibicen flammatus photo by Osamu Hikino.

The second paper is Molecular phylogenetics, diversification, and systematics of Tibicen Latreille 1825 and allied cicadas of the tribe Cryptotympanini, with three new genera and emphasis on species from the USA and Canada (Hemiptera: Auchenorrhyncha: Cicadidae) by Kathy B. R. Hill, David C. Marshall, Maxwell S. Moulds & Chris Simon. 2015, Zootaxa 3985 (2): 219–251. This paper establishes the Neotibicen (Hill and Moulds), and Hadoa (Moulds) genera. This paper also sought to establish the Subsolanus genera for the Asian Tibicen/Lyristes species but the previously mentioned paper by Young June Lee has precedence because it was published first. Link to paper.

To recap, European Tibicen/Lyristes are Tibicen

Adult Tibicen/Lyristes plebejus
Tibicen plebejus photo by Iván Jesus Torresano García.

… Asian Tibicen/Lyristes are now Auritibicen. Mostly-eastern North American Tibicen are now Neotibicen, and Western North American Tibicen are now Hadoa. Note that, the catagorization is not due to location, but to genetic and physiological evaluation (read the papers).

Needless to say this website and others have a lot of name changing to do, but in the mean time, here’s where the North American species fall out:

Neotibicen
Tibicen auletes Neotibicen auletes
Tibicen auriferus Neotibicen auriferus
Tibicen canicularis Neotibicen canicularis
Tibicen cultriformis Neotibicen cultriformis
Tibicen davisi davisi Neotibicen davisi davisi
Tibicen davisi harnedi Neotibicen davisi harnedi
Tibicen dealbatus Neotibicen dealbatus
Tibicen dorsatus Neotibicen dorsatus
Tibicen figuratus Neotibicen figuratus
Tibicen latifasciatus Neotibicen latifasciatus
Tibicen linnei Neotibicen linnei
Tibicen lyricen engelhardti Neotibicen lyricen engelhardti
Tibicen lyricen lyricen Neotibicen lyricen lyricen
Tibicen lyricen virescens Neotibicen lyricen virescens
Tibicen pronotalis pronotalis Neotibicen pronotalis pronotalis
Tibicen pronotalis walkeri Neotibicen pronotalis walkeri
Tibicen pruinosus fulvus Neotibicen pruinosus fulvus
Tibicen pruinosus pruinosus Neotibicen pruinosus pruinosus
Tibicen resh Neotibicen resh
Tibicen resonans Neotibicen resonans
Tibicen robinsonianus Neotibicen robinsonianus
Tibicen similaris Neotibicen similaris
Tibicen superbus Neotibicen superbus
Tibicen tibicen australis Neotibicen tibicen australis
Tibicen tibicen tibicen Neotibicen tibicen tibicen
Tibicen tremulus Neotibicen tremulus
Tibicen winnemanna Neotibicen winnemanna
Hadoa
Tibicen bifidus Hadoa bifida
Tibicen chiricahua Hadoa chiricahua
Tibicen duryi Hadoa duryi
Tibicen inauditus Hadoa inaudita
Tibicen longioperculus Hadoa longiopercula
Tibicen neomexicensis Hadoa neomexicensis
Tibicen parallelus Hadoa parallela
Tibicen simplex Hadoa simplex
Tibicen texanus Hadoa texana
Tibicen townsendii Hadoa townsendii

You can see some of those species here by their old names. :)

December 17, 2014

Behold a molting Tibicen

Filed under: Tibicen — Tags: — Dan @ 5:48 am

Walter Abington sent us this series of photographs of a molting Tibicen cicada. I believe the cicada is a Tibicen pruinosus based on this guide to identifying teneral Tibicen.

A molting Tibicen

November 20, 2014

Watch a Tibicen nymph emerge from the ground

Filed under: Roy Troutman,Tibicen,Video — Dan @ 5:38 am

This video by Roy Troutman shows a Tibicen cicada nymph emerge from the ground.

Annual cicada nymph emerging from burrow. from Roy Troutman.

A Tibicen cicada breathing

Filed under: Cicada Anatomy,Roy Troutman,Tibicen,Video — Dan @ 5:31 am

Cicadas breathe through apertures along the side of their body called spiracles. This video of a Tibicen by Roy Troutman shows the opening and closing of a spiracle.

Adult Cicada breathing from Roy Troutman on Vimeo.

Older Posts »
